#include <simSet.h>

Inheritance diagram for SimSet:

Public Member Functions
	SimSet ()

	~SimSet ()

virtual void	onRemove ()
	Called when the object is removed from the sim. More...

virtual void	onDeleteNotify (SimObject *object)

virtual U32	getTamlChildCount (void) const
	Called when Taml attempts to compile a list of children. More...

virtual SimObject *	getTamlChild (const U32 childIndex) const
	Called when Taml attempts to compile a list of children. More...

virtual void	addTamlChild (SimObject *pSimObject)
	Called when Taml attempts to populate an objects children during a read. More...

void	callOnChildren (const char method, S32 argc, const char argv[], bool executeOnChildGroups=true)

virtual void	write (Stream &stream, U32 tabStop, U32 flags=0)

virtual SimObject *	findObject (const char *name)

SimObject *	findObjectByInternalName (const char *internalName, bool searchChildren=false)

virtual bool	writeObject (Stream *stream)

virtual bool	readObject (Stream *stream)

void	lock ()

void	unlock ()

	DECLARE_CONOBJECT (SimSet)

void	_setVectorAssoc (const char *file, const U32 line)

Set Management
virtual void	addObject (SimObject *)
	Add an object to the set. More...

virtual void	removeObject (SimObject *)
	Remove an object from the set. More...

virtual void	pushObject (SimObject *)

virtual void	popObject ()
	Remove an object from the end of the list. More...

void	bringObjectToFront (SimObject *obj)

void	pushObjectToBack (SimObject *obj)

Public Member Functions inherited from SimObject
StringTableEntry	getClassNamespace () const

StringTableEntry	getSuperClassNamespace () const

void	setClassNamespace (const char *classNamespace)

void	setSuperClassNamespace (const char *superClassNamespace)

void	pushScriptCallbackGuard (void)

void	popScriptCallbackGuard (void)

S32	getScriptCallbackGuard (void)

Namespace *	getNamespace ()
	Return the object's namespace. More...

const char *	tabComplete (const char *prevText, S32 baseLen, bool)

virtual void	dump ()

virtual void	dumpClassHierarchy ()

SimObject *	clone (const bool copyDynamicFields)

virtual void	copyTo (SimObject *object)

template<typename T >
bool	isType (void)

virtual bool	handlesConsoleMethod (const char fname, S32 routingId)

	DECLARE_CONOBJECT (SimObject)

Notify *	removeNotify (void *ptr, Notify::Type)
	Remove a notification from the list. More...

void	deleteNotify (SimObject *obj)
	Notify an object when we are deleted. More...

void	clearNotify (SimObject *obj)
	Notify an object when we are cleared. More...

void	clearAllNotifications ()
	Remove all notifications for this object. More...

void	processDeleteNotifies ()
	Send out deletion notifications. More...

void	registerReference (SimObject **obj)

void	unregisterReference (SimObject **obj)

const char *	getDataField (StringTableEntry slotName, const char *array)

void	setDataField (StringTableEntry slotName, const char array, const char value)

const char *	getPrefixedDataField (StringTableEntry fieldName, const char *array)

void	setPrefixedDataField (StringTableEntry fieldName, const char array, const char value)

const char *	getPrefixedDynamicDataField (StringTableEntry fieldName, const char *array, const S32 fieldType=-1)

void	setPrefixedDynamicDataField (StringTableEntry fieldName, const char array, const char value, const S32 fieldType=-1)

StringTableEntry	getDataFieldPrefix (StringTableEntry fieldName)

U32	getDataFieldType (StringTableEntry slotName, const char *array)

SimFieldDictionary *	getFieldDictionary ()

void	clearDynamicFields (void)
	Clear all dynamic fields. More...

void	setCanSaveDynamicFields (bool bCanSave)
	Set whether fields created at runtime should be saved. Default is true. More...

bool	getCanSaveDynamicFields (void) const
	Get whether fields created at runtime should be saved. Default is true. More...

void	setInternalName (const char *newname)

StringTableEntry	getInternalName ()
	Get the internal of of this control. More...

virtual bool	save (const char *pcFilePath, bool bOnlySelected=false)
	Save object as a TorqueScript File. More...

virtual bool	isMethod (const char *methodName)
	Check if a method exists in the objects current namespace. More...

SimObjectId	getId (void) const

StringTableEntry	getIdString (void) const

U32	getType () const

const StringTableEntry	getName (void) const

void	setId (SimObjectId id)

void	assignName (const char *name)

SimGroup *	getGroup () const

bool	isChildOfGroup (SimGroup *pGroup)

bool	isProperlyAdded () const

bool	isDeleted () const

bool	isRemoved () const

bool	isLocked ()

void	setLocked (bool b)

bool	isHidden ()

void	setHidden (bool b)

void	setProgenitorFile (const char *pFile)

StringTableEntry	getProgenitorFile (void) const

void	setPeriodicTimerID (const S32 timerID)

S32	getPeriodicTimerID (void) const

bool	isPeriodicTimerActive (void) const

bool	isSelected () const

bool	isExpanded () const

void	setSelected (bool sel)

void	setExpanded (bool exp)

void	setModDynamicFields (bool dyn)

void	setModStaticFields (bool sta)

	SimObject (const U8 namespaceLinkMask=LinkSuperClassName\|LinkClassName)

virtual	~SimObject ()

virtual bool	processArguments (S32 argc, const char **argv)
	Process constructor options. (ie, new SimObject(1,2,3)) More...

virtual bool	onAdd ()
	Called when the object is added to the sim. More...

virtual void	onGroupAdd ()
	Called when the object is added to a SimGroup. More...

virtual void	onGroupRemove ()
	Called when the object is removed from a SimGroup. More...

virtual void	onNameChange (const char *name)
	Called when the object's name is changed. More...

virtual void	onStaticModified (const char slotName, const char newValue=NULL)

virtual void	inspectPreApply ()

virtual void	inspectPostApply ()

virtual void	onEditorEnable ()
	Called when the editor is activated. More...

virtual void	onEditorDisable ()
	Called when the editor is deactivated. More...

bool	registerObject ()

bool	registerObject (U32 id)

bool	registerObject (const char *name)

bool	registerObject (const char *name, U32 id)

void	unregisterObject ()

void	deleteObject ()

bool	addToSet (SimObjectId)

bool	addToSet (const char *)

bool	removeFromSet (SimObjectId)

bool	removeFromSet (const char *)

virtual bool	writeField (StringTableEntry fieldname, const char *value)

virtual void	writeFields (Stream &stream, U32 tabStop)

virtual void	buildFilterList ()

void	addFieldFilter (const char *fieldName)

void	removeFieldFilter (const char *fieldName)

void	clearFieldFilters ()

bool	isFiltered (const char *fieldName)

void	assignFieldsFrom (SimObject *obj)

void	assignDynamicFieldsFrom (SimObject *obj)

Public Member Functions inherited from ConsoleObject
const AbstractClassRep::Field *	findField (StringTableEntry fieldName) const
	Get a reference to a field by name. More...

virtual AbstractClassRep *	getClassRep () const
	Gets the ClassRep. More...

bool	setField (const char fieldName, const char value)
	Set the value of a field. More...

virtual	~ConsoleObject ()

const AbstractClassRep::FieldList &	getFieldList () const
	Get a list of all the fields. This information cannot be modified. More...

AbstractClassRep::FieldList &	getModifiableFieldList ()

bool &	getDynamicGroupExpand ()

S32	getClassId (U32 netClassGroup) const

const char *	getClassName () const

Protected Attributes
SimObjectList	objectList

void *	mMutex

Protected Attributes inherited from SimObject
SimObjectId	mId
	Id number for this object. More...

StringTableEntry	mIdString

Namespace *	mNameSpace

U32	mTypeMask

S32	mScriptCallbackGuard
	Whether the object is executing a script callback. More...

bool	mCanSaveFieldDictionary
	true if dynamic fields (added at runtime) should be saved, defaults to true More...

StringTableEntry	mInternalName
	Stores object Internal Name. More...

StringTableEntry	mClassName
	Stores the class name to link script class namespaces. More...

StringTableEntry	mSuperClassName
	Stores super class name to link script class namespaces. More...

U8	mNSLinkMask

STL Interface
typedef SimObjectList::iterator	iterator

typedef SimObjectList::value_type	value

SimObject *	front ()

SimObject *	first ()

SimObject *	last ()

bool	empty ()

S32	size () const

iterator	begin ()

iterator	end ()

value	operator[] (S32 index)

iterator	find (iterator first, iterator last, SimObject *obj)

iterator	find (SimObject *obj)

template<typename T >
bool	containsType (void)

virtual bool	reOrder (SimObject obj, SimObject target=0)

SimObject *	at (S32 index) const

void	deleteObjects (void)

void	clear ()

Additional Inherited Members
Public Types inherited from SimObject
enum	WriteFlags { SelectedOnly = BIT(0) }

Static Public Member Functions inherited from SimObject
static void	initPersistFields ()

Protected Types inherited from SimObject
enum	SimObjectNSLinkType { LinkClassName = BIT(0), LinkSuperClassName = BIT(1) }

Protected Member Functions inherited from SimObject
virtual void	onTamlPreWrite (void)
	Taml callbacks. More...

virtual void	onTamlPostWrite (void)
	Called after Taml has finished writing the object. More...

virtual void	onTamlPreRead (void)
	Called prior to Taml reading the object. More...

virtual void	onTamlPostRead (const TamlCustomNodes &customNodes)

virtual void	onTamlAddParent (SimObject *pParentObject)
	Called after Taml has finished reading the object and has added the object to any parent. More...

virtual void	onTamlCustomWrite (TamlCustomNodes &customNodes)
	Called during the writing of the object to allow custom properties to be written. More...

virtual void	onTamlCustomRead (const TamlCustomNodes &customNodes)
	Called during the reading of the object to allow custom properties to be read. More...

void	linkNamespaces ()

void	unlinkNamespaces ()

Static Protected Member Functions inherited from SimObject
static bool	setClass (void obj, const char data)

static bool	setSuperClass (void obj, const char data)

static bool	writeCanSaveDynamicFields (void *obj, StringTableEntry pFieldName)

static bool	writeInternalName (void *obj, StringTableEntry pFieldName)

static bool	setParentGroup (void obj, const char data)

static bool	writeParentGroup (void *obj, StringTableEntry pFieldName)

static bool	writeSuperclass (void *obj, StringTableEntry pFieldName)

static bool	writeClass (void *obj, StringTableEntry pFieldName)

static SimObject::Notify *	allocNotify ()
	Get a free Notify structure. More...

static void	freeNotify (SimObject::Notify *)
	Mark a Notify structure as free. More...

Static Protected Attributes inherited from SimObject
static SimObject::Notify *	mNotifyFreeList = NULL

Detailed Description

A set of SimObjects.

It is often necessary to keep track of an arbitrary set of SimObjects. For instance, Torque's networking code needs to not only keep track of the set of objects which need to be ghosted, but also the set of objects which must always be ghosted. It does this by working with two sets. The first of these is the RootGroup (which is actually a SimGroup) and the second is the GhostAlwaysSet, which contains objects which must always be ghosted to the client.

Some general notes on SimSets:

Membership is not exclusive. A SimObject may be a member of multiple SimSets.
A SimSet does not destroy subobjects when it is destroyed.
A SimSet may hold an arbitrary number of objects.

Using SimSets, the code to work with these two sets becomes relatively straightforward:

// (Example from netObject.cc)
// To iterate over all the objects in the Sim:
for (SimSetIterator obj(Sim::getRootGroup()); *obj; ++obj)
{
          NetObject* nobj = dynamic_cast<NetObject*>(*obj);
         if (nobj)
           {
             // ... do things ...
         }
 }
 // (Example from netGhost.cc)
 // To iterate over the ghostAlways set.
 SimSet* ghostAlwaysSet = Sim::getGhostAlwaysSet();
 SimSet::iterator i;
 U32 sz = ghostAlwaysSet->size();
 S32 j;
 for(i = ghostAlwaysSet->begin(); i != ghostAlwaysSet->end(); i++)
 {
     NetObject *obj = (NetObject *)(*i);
 }

Member Typedef Documentation

typedef SimObjectList::iterator iterator

typedef SimObjectList::value_type value

Constructor & Destructor Documentation

SimSet ( )

inline

~SimSet ( )

inline

Member Function Documentation

void _setVectorAssoc	(	const char *	file,
		const U32	line
	)

inline

void addObject ( SimObject * obj )

virtual

Add an object to the set.

Reimplemented in GuiControl, SimGroup, GuiScrollCtrl, GuiFrameSetCtrl, GuiFormCtrl, GuiRolloutCtrl, GuiStackControl, GuiDynamicCtrlArrayControl, and GuiGridControl.

virtual void addTamlChild ( SimObject * pSimObject )

inlinevirtual

Called when Taml attempts to populate an objects children during a read.

Implements TamlChildren.

SimObject* at ( S32 index ) const

inline

iterator begin ( )

inline

void bringObjectToFront ( SimObject * obj )

inline

void callOnChildren	(	const char *	method,
		S32	argc,
		const char *	argv[],
		bool	executeOnChildGroups = `true`
	)

void clear ( )

bool containsType ( void )

inline

DECLARE_CONOBJECT ( SimSet )

void deleteObjects ( void )

bool empty ( )

inline

iterator end ( void )

inline

iterator find	(	iterator	first,
		iterator	last,
		SimObject *	obj
	)

inline

iterator find ( SimObject * obj )

inline

SimObject * findObject ( const char * name )

virtual

Find a named sub-object of this object.

This is subclassed in the SimGroup and SimSet classes.

For a single object, it just returns NULL, as normal objects cannot have children.

Reimplemented from SimObject.

Reimplemented in SimGroup.

SimObject * findObjectByInternalName	(	const char *	internalName,
		bool	searchChildren = `false`
	)

SimObject* first ( )

inline

SimObject* front ( )

inline

virtual SimObject* getTamlChild ( const U32 childIndex ) const

inlinevirtual

Called when Taml attempts to compile a list of children.

Implements TamlChildren.

virtual U32 getTamlChildCount ( void ) const

inlinevirtual

Called when Taml attempts to compile a list of children.

Implements TamlChildren.

SimObject* last ( )

inline

void lock ( )

inline

void onDeleteNotify ( SimObject * object )

virtual

Called when a SimObject is deleted.

When you are on the notification list for another object and it is deleted, this method is called.

Reimplemented from SimObject.

void onRemove ( )

virtual

Called when the object is removed from the sim.

Reimplemented from SimObject.

Reimplemented in NetConnection, GuiControl, SimGroup, GameConnection, SceneWindow, GuiTabBookCtrl, GuiEditCtrl, GuiTextListCtrl, and GuiMessageVectorCtrl.

value operator[] ( S32 index )

inline

void popObject ( )

virtual

Remove an object from the end of the list.

It will force the object to the end of the list if it already exists in the list.

void pushObject ( SimObject * pObj )

virtual

Add object to end of list.

void pushObjectToBack ( SimObject * obj )

inline

bool readObject ( Stream * stream )

virtual

Reimplemented from SimObject.

void removeObject ( SimObject * obj )

virtual

Remove an object from the set.

Reimplemented in SimGroup, GuiControl, GuiFrameSetCtrl, GuiRolloutCtrl, GuiStackControl, and GuiGridControl.

bool reOrder	(	SimObject *	obj,
		SimObject *	target = `0`
	)

virtual

Reimplemented in GuiStackControl.

S32 size ( ) const

inline

void unlock ( )

inline

void write	(	Stream &	stream,
		U32	tabStop,
		U32	flags = `0`
	)

virtual

Output the TorqueScript to recreate this object.

This calls writeFields internally.

Parameters

stream	Stream to output to.
tabStop	Indentation level for this object.
flags	If SelectedOnly is passed here, then only objects marked as selected (using setSelected) will output themselves.

Reimplemented from SimObject.

Reimplemented in GuiControl, and NameTags.

bool writeObject ( Stream * stream )

virtual

Reimplemented from SimObject.

Member Data Documentation

void* mMutex

protected

SimObjectList objectList

protected

The documentation for this class was generated from the following files:

sim/simSet.h
sim/simSerialize.cpp
sim/simSet.cc

Public Member Functions

Protected Attributes

STL Interface

Additional Inherited Members

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
